KAB-PHR-NN-LLLL-XX

The connector series JST PHR are very popular and frequently used as e.g. inverter connectors on displays or other equipment. For this reason there are many different types of this series available from stock. The part numbers are composed as follows:

KAB-PHR-NN-LLLLXX

KAB -> cable assembling PHR -> connector series NN -> pin number, e.g. 05 = 5 pin, 10 = 10 pin LLLL -> length, e.g. 0500 = 500 mm, 0750 = 750 mm XX -> FK = flat cable LI = wire Cables with this part numbers are unprocessed on one side. We can also quote and produce complete assembled cables according to your requirements.

Product Notes

Wire: Color coded flatcable, AWG28, UL2651 or single wire in max. AWG24

Contacts: SPH-002T-P0.5S (AWG30-24), SPH-004T-P0.5S (AWG32-28)

Popular versions (partially available from stock):

KAB-PHR-03-0500FK

Fits with PCB headers: B3B-PH-KL, S3B-PH-KL, B3B-PH-SM4-TB, S3B-PH-SM4-TB, 20010WR-03, 20010WS-03, 20022WR-03, M22-3070300, M22-220346

Fits with the following LCD backlight inverters or other equipment: INVC473, EE-SPX414-P1, INVC329, ECL10, Sharp Sensor GP2Y0D413K0F, GP2Y0D21YK0F, GF20A41SK0F, GP2Y0A21YK0F, GP2Y0D21YK0F

Compatible with the following connectors: CI01-03S0000

KAB-PHR-04-0500FK

Fits with PCB headers: B4B-PH-KL, S4B-PH-KL, B4B-PH-SM4-TB, S4B-PH-SM4-TB, 20010WR-04, 20010WS-04, 20022WR-04, M22-3070400, M22-220446

Fits with the following LCD backlight inverters or other equipment: A2TPMI, ECL15, LQ4NC01, LQ4NC02, TMCM-110-42, PrismaECO-eDP

Compatible with the following connectors: CI01-04S0000

KAB-PHR-05-0500FK

Fits with PCB headers: B5B-PH-KL, S5B-PH-KL, B5B-PH-SM4-TB, S5B-PH-SM4-TB, 20010WR-05, 20010WS-05, 20022WR-05, M22-3070500, M22-220546, 721-81-05TW00, A2001WV-05P146

Fits with the following LCD backlight inverters or other equipment: CSA-0217, CXA-0271, CXA-P102NJL, CXA-P1024-NJL, CXA-0457, CXA-P1612-VJL, CXA0231, FTP-644MCL001, FTP-624DCL, INVC132

Compatible with the following connectors: CI01-05S0000

KAB-PHR-06-0500FK

Fits with PCB headers: B6B-PH-KL, S6B-PH-KL, B6B-PH-SM4-TB, S6B-PH-SM4-TB, 20010WR-06, 20010WS-06, 20022WR-06, M22-3070600, M22-220646

Fits with the following LCD backlight inverters or other equipment: FLC56XWC8V, LQ370T3LZ39, LQ315T3LZ19, LQ445D3LZ19, LQ255T3LZ19, A2TPMI

Compatible with the following connectors: CI01-06S0000

KAB-PHR-07-0500FK

Fits with PCB headers: B7B-PH-KL, S7B-PH-KL, B7B-PH-SM4-TB, S7B-PH-SM4-TB, 20010WR-07, 20010WS-07, 20022WR-07, M22-3070700, M22-220746

Fits with the following LCD backlight inverters or other equipment: CXA-0384, CXA0349, CXA0377C, CXA-0453, CXA-0315, CXA-0385, CXA-0346, CXA-0286, AA150XN01, CXA-46012PJ106, CXA-46012PJ107, CXA-46012PJ108, CXA-46012PJ109

Compatible with the following connectors: CI01-07S0000

KAB-PHR-08-0500FK

Fits with PCB headers: B8B-PH-KL, S8B-PH-KL, B8B-PH-SM4-TB, S8B-PH-SM4-TB, 20010WR-08, 20010WS-08, 20022WR-08, M22-3070800, M22-220846, HWA-411087-R00, L-WA108083R74, RWA-411087-R00, A2001WV-F-08PR6RT1NY7G

Fits with the following LCD backlight inverters or other equipment: ITSX98E, TMCM-110-42, DmF63359, DLF_DLH1975, PS-LD0608-01

Compatible with the following connectors: CI01-08S0000

KAB-PHR-09-0500FK

Fits with PCB headers: B9B-PH-KL, S9B-PH-KL, B9B-PH-SM4-TB, S9B-PH-SM4-TB, 20010WR-09, 20010WS-09, 20022WR-09, M22-3070900, M22-220946

Fits with the following LCD backlight inverters or other equipment: FTP-644MCL001, FTP-624DCL

Compatible with the following connectors: CI01-09S0000

KAB-PHR-10-0500FK

Fits with PCB headers: B10B-PH-KL, S10B-PH-KL, B10B-PH-SM4-TB, S10B-PH-SM4-TB, 20010WR-10, 20010WS-10, 20022WR-10, M22-3071000, M22-221046, CI0110M1HR0-NH

Fits with the following LCD backlight inverters or other equipment: FTP-644MCL001, FTP-624DCL, FTP-634MC, Navimec™ modules, T9902128, T9902127, LQ315T3LZ19, LQ445D3LZ19, FLC56XWC8V, G215HCJ-LH1, T650HVF01.0, G215HVN01.3, G215HCJ-LH1, G170ECE-LE2

Compatible with the following connectors: CI01-10S0000

KAB-PHR-11-0500FK

Fits with PCB headers: B11B-PH-KL, S11B-PH-KL, B11B-PH-SM4-TB, S11B-PH-SM4-TB, 20010WR-11, 20010WS-11, 20022WR-11, M22-3071100, M22-221146

Fits with the following LCD backlight inverters or other equipment: FTP-644NCL001, FTP-624DCL

Compatible with the following connectors: CI01-11S0000

KAB-PHR-12-0500FK

Fits with PCB headers: B12B-PH-KL, S12B-PH-KL, B12B-PH-SM4-TB, S12B-PH-SM4-TB, 20010WR-12, 20010WS-12, 20022WR-12, M22-3071200, M22-221246

Fits with the following LCD backlight inverters or other equipment: LC320W01, V201T01, V420H1-L03, T460HW01/LC370, LC370, LC230W01, LQ197V3DZ89, LC370WX1, FCL56XWC8V, LD520WU1, LD470WUB, LC470WUN, PS-LD0608-02, PS-LD1601-x, P420IVN01.0

Compatible with the following connectors: CI01-12S0000

KAB-PHR-13-0500FK

Fits with PCB headers: B13B-PH-KL, S13B-PH-KL, B13B-PH-SM4-TB, S13B-PH-SM4-TB, 20010WR-13, 20010WS-13, 20022WR-13, M22-3071300, M22-221346

Fits with the following LCD backlight inverters or other equipment: LTM150X1-A1, LE420AQU

Compatible with the following connectors: CI01-13S0000

KAB-PHR-14-0500FK

Fits with PCB headers: B14B-PH-KL, S14B-PH-KL, B14B-PH-SM4-TB, S14B-PH-SM4-TB, 20010WR-14, 20010WS-14, 20022WR-14, M22-3071400, M22-221446, CI0114M1HRL-NH

Fits with the following LCD backlight inverters or other equipment: LD520WU1, LD470WUB, LC470WUN, LC420WUN, LD420WUB, LC370WUN, LC370WXN, LC320WXN, LC260WX2, LC200WX1, LTI400HA02, V470H2-L01, LC170WXN, P645HW04V0, LD320EUN-SEM1, G260JJE-L07, G240UAN01.0, G240UAN01.1, G270ZAN01.0, G270ZAN01.1, LD320EUN-SEM1, G320ZAN01.0, SL3228ML-L1A, SL3229ML-L3, LD420EUB-SDA1, LD420EUN-UHA1, SL4238ML-HGB, LTI370LN03-V, GH682A, GH680A, P420IVN01.0, S290AJ1-LE1, P370IVN02.0, P550HVN03.2, GH812A, P320HVN07.0, LD750DGN, P370IVN04.0

Compatible displays: AUO P430HVN06.1, AUO P550HVN06.6

Compatible with the following connectors: CI01-14S0000

KAB-PHR-15-0500FK

Fits with PCB headers: B15B-PH-KL, S15B-PH-KL, B15B-PH-SM4-TB, S15B-PH-SM4-TB, 20010WR-15, 20010WS-15, 20022WR-15, M22-30701500, M22-221546

Fits with crimpcontact: SPH-002T-P0.5S, SPH-004T-P0.5S

Fits with the following LCD backlight inverters or other equipment: LTI400HA10

Compatible with the following connectors: CI01-15S0000

This KAB-PHR-series supports the following LCD: OT104ASDDLV-02, Dimension

Lenght: 500,0 mm

Operating temperature -20 °C to 85 °C
