AWG30 Round Cable | 12-pin

LTG-MPPE-12XAWG30B-UL21455-WH

This 12-pin unshielded round wire AWG30 with a strand diameter of only 0.60 mm is especially designed for LED backlight applications. AWG30, unshielded 12-pin, tin-coated copper strand no halogens, LSOH and RoHS free

outer diameter: 4.7 mm

strand diameter: 0.60 mm

insulation jacket: MPPE-PE

white wire, cable roll = 1000 m

operating temperature: -10°C to 80°C,30V

UL 21455 This cable is also available from in a 5 or 10 twisted pair version ( LTG-MPPE-5X2XAWG30B-UL21455-WH / LTG-MPPE-10X2XAWG30B-UL21455-WH )
