FFC for HIROSE FH41/FH48 | pitch: 0.50 mm | 20-pin FFC0.50A20-0116L-2-2-06-06-AU-SC-FH41 This FFC cable is suitable for the connector series of the manufacturer Hirose FH41 and FH48. The special feature of this FFC cable, besides the side-catcher, is the galvanically gold-plated conductor tracks, this variant is often desired if the contacting connector has gold-plated contact tongues. In addition, the aluminum foil ensures optimum signal shielding. FFC, 20-pin

pitch: 0.50 mm (+/- 0.05 mm)

cross sections: 0.05.x0.32 mm (+/- 0.05 mm)

contact length: 2 mm (+/- 0.5 mm)

reinforcement length: 6 mm (+/- 1.50 mm)

contact strength in the mating area: 0.3 mm (+/- 0.05 mm)

total length: 120 mm

UL 2896 (80 ° C, 30V) AC, VW-1

weight: 0.7 g

This FFC cable does not quite fit your expectations? No problem - just configure your own FFC cable with our FFC configurator . Matching connectors: FH41-20S-0.5SH(05), FH41-20S-0.5SH(99), FH48-20S-0.5SV
