Manufacturer Information Electronic Piezo Signal Transmitter BUZZER-PIEZO-17X4-LITZE Manufacturer Information Get to know our new piezoelectric signal transmitter – the Buzzer! It is the perfect companion for all applications where an acoustic signal is needed. The Buzzer has two stranded wires that allow it to be easily and quickly connected to other components. Installation is very simple and requires no prior knowledge. The buzzer is also extremely reliable and can easily withstand harsh conditions.

Buzzer: Piezo

Dimensions: Ø 16.3 mm +/- 5 mm x 4 mm

Voltage range: 3 ~ 30 Vp-p (max.)

Frequency: 4 kHz

Sound pressure level: 72 dB

Without generator Without mounting flange

Operating temperature: -20 °C to 70 °C

Stranded wire: UL1571, AWG30

Length: 40 mm +/- 5 mm

The Buzzer's field of application is extremely diverse. For example, it can be used in alarm technology to draw attention to dangers. It is also frequently used in consumer electronics to play sounds and music. Thus, signal generators are used in digital watches, electronic calculators, telephones and numerous other devices. An additional field of application is the automotive industry, where it is used as an acoustic signal when functions are activated. In short, the Buzzer is an indispensable component for anyone who needs a reliable and easy-to-install acoustic signal.

Product number: KS-1704T2W40A (Dongguan Cosson Electronic Plastic Co., Ltd.)

Comparable products: PKM17EWH4000 (Murata), KPEG150 (Kingstate)
